Home > Diesel Powered Forklift >

Yellow 3 Ton Diesel Forklift Warehouse Lift Truck 1070mm Fork Length

Product Categories

ANHUI VMAX TECHNOLOGY CO., LTD

Contact Now

Name: Yellow 3 Ton Diesel Forklift Warehouse Lift Truck 1070mm Fork Length
Brand: Vmax
Price: 1 USD

Brand Name : Vmax

Model Number : CPCD30

Certification : ISO CE, SGS, BV

Place of Origin : ANHUI,CHINA

MOQ : 1UNIT

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000unit / year

Delivery Time : 45 DAYS

Packaging Details : bubble wrap

product name : diesel forklift truck

Condition : new

Type : Manual Pallet Truck

Power Souce : Diesel Engine

Rated Loading Capacity : 3000kg

Max. Lifting Height : 6000mm

Min. Lifting Height : 3000mm

Fork Length : 1070mm

color : yellow or custom made

Weight : 4700kg

Contact Now

Yellow 3 Ton Diesel Forklift Warehouse Lift Truck 1070mm Fork Length

counterbalance fork truck Characteristics:

3T COUNTER BALANCE DIESEL FORKLIFT TRUCK SPECIFICATION
Model		Unit	CPC30/CPCD30
Power type			Diesel
Rated capacity		kg	3000
Load center		mm	500
Mast Lifting height		mm	3000
Free lift height		mm	175
Fork size(LWT)		mm	1070×125×45
Tilting Angles(Front/Rear)		deg	6°/12°
Front overhang		mm	485
Exterior Size	Length without fork	mm	2680
	Overall width	mm	1225
	Mast drop	mm	2065
	Max.lift	mm	4250
	Front-wheel Overhead	mm	2070
Min Turning Radius		mm	2420
Min.intersecting aisle		mm	2100
Speeds	Max Driving speeds	km/h	18.5/20
	Lifting speeds	mm/s	470/520
	Lowering speeds	mm/s	550/520
Max.grade ability		%	20
Total weight		kg	4300
Tires	Front		28*9-15-12PR
Tires	Rear		6.5-10-10PR
Wheelbase		mm	1700
Tread	Front	mm	1000
Tread	Rear	mm	970
Min.ground clearance		mm	110
Engine	Model		490BPG
	Rated output	kw/rpm	37/2650
	Rated torque	N.m/rpm	148/1800
	No.of cylinder		4
	Displacement	L	2.54
Fuel tank capacity		L	52

Yellow 3 Ton Diesel Forklift Warehouse Lift Truck 1070mm Fork Length
